Vector Network Analyzer - Bode 100
New - Extended frequency range 1 Hz - 40 MHz

Bode 100 - Cost effective test set which can be a Vector Network Analyzer, Gain Phase Meter, Impedance Meter, & Sine Wave Generator.

  • The frequency range 1 Hz - 40 MHz is ideal for LF, audio, video and RF application.
  • The accuracy makes it perfect for R&D labs, manufacturing and training.
  • The compact lightweight design is perfect for service and maintenance purposes.
  • The automation interface fits the needs of production fields.
  • The price / performance value benefits professionals such as engineers, scientists and teachers engaged in the field of electronics.

With its flexibility, accuracy and price / performance, Bode 100 can benefit professionals and teachers in the electronic field.




It’s amazing what this compact, cost effective test set can do!

If the wide frequency range from 1Hz to 40MHz fits your needs, the full beauty of Bode 100 will impress you. With Bode 100 and the included Analyzer software, you are all set for your daily RF challenges.

With Bode 100, you are ready to measure:

  • complex gain of amplifiers and filters
  • influence of termination on amplifiers or filters
  • complex impedance and admittance
  • reflection coefficient and return loss
  • frequency dependent impedance of high-Q circuits like oscillating crystals
  • reflection of a circuit, and display in a Smith chart and/or
  • reflection of antennas and display in VSWR format
  • swept S-parameters of electronic circuits (filters, amplifiers, bipolar transistors ... )
  • Bode plots of control circuits
  • group delay characteristics of your DUT
  • stability analysis of open loops (Nyquist criterion)
  • and more ...

For more information, check the system, technical data, and software sections.



What is New


New Bode Analyzer Suite V2.2 availiable: Enjoy new data reporting functions, new measurement modes and an extended frequency range
To help you utilize the full potential of your Bode 100, we have established a new Application note section
